Air |
||
|
|
Double-Acting |
||
|
|
0.6(6.1) |
||
|
|
-10~60℃ |
||
|
|
±0.1mm |
||
|
|
M5×0.8 |
G1/8" |
|
Fluid
|
Bore(mm) |
10 |
16 |
20 |
25 |
32 |
40 |
|
Fluid |
Air |
|||||
|
Motion Pattern |
Double-Acting |
|||||
|
Max.pressure Mpa(kgf/cn2) |
0.6(6.1) |
|||||
|
Max.pressure Mpa(kgf/cn2) |
0.15(1.5) |
0.1(1.0) |
||||
|
Ambient and fluid temperature |
-10~60℃ |
|||||
|
Repeatability Precision(mm) |
±0.1mm |
|||||
|
Effective gripping force (N) at 0.5 Mpa |
14 |
45 |
74 |
131 |
228 |
396 |
|
Port Size |
M5×0.8 |
G1/8" |
||||
