Series: XU Series F.R.L
 Gauge
|
G1/4"
|
|
Operating Fluid
|
Air
|
|
Pressure Range
|
0.05-0.85MPa
|
|
Ambient Temperature
|
-10-60℃
|
|
Filter Precision
|
20µm
|
|
Oil Recommended
|
Turbine oil(ISO VG32)
|
| Model |
XUC/WL/W-02 |
XUC/WL/W-03 |
XUC/WL/W-04 |
XUC/WL/W-06 |
XUC/WL/W-08 |
| XUF/R/L-02 | XUF/R/L-03 | XUF/R/L-04 | XUF/R/L-06 | XUF/R/L-08 | |
| Port Size |
G1/4" |
G3/8" | G1/2" | G3/4" | G1" |
| Gauge | 1/4" | ||||
| Fluid | Air | ||||
| Pressure Range | 0.05-0.85MPa | ||||
| Max.Flow rate(NI/min) | 2050 | 2500 | 7900 | 8100 | |
| Ambient Temperature | -10-60℃ | ||||
| Filter Precision | 20 | ||||
| Oil Recommended | Turbine oil(ISO VG32) | ||||
| Cup Material | Polycarbonate | ||||
| Structure | Distom type | ||||
Accurate requlation of an optimal air fl...
Accurate regulation of an optimal airflo...
One-Touch push-to-connect configuration ...
