Tube CutterThis kind of valve widely used in wide different industry, you can find the valve with different material like brass, stainless steel, engineering plastic, and they are used for pressure range from 0 to 50 bar, temperature from -10 °C to 180°C. If there is no current models with your meet, please contact us, weare available to provide specialized valves according to your requirement.
 Morking Medium
|
Air,Water,Oil
|
|
Type
|
Normal Close Type
|
|
Operation Fluid Viscosity
|
20 CST (Below)
|
|
Operating Temperature Range
|
-10~+80℃
|
|
Voltage Range
|
±10%
|
|
Protect Class
|
IP65
|
|
Working Medium
|
Air,Water,Oil,Gas
|
|
Motion Pattern
|
Direct Drive Type
|
|
Type
|
Normal Close Type
|
|
Aperture of Flow Rate(mm)
|
2.5
|
|
CV Value
|
0.23
|
|
Operation Fluid Viscosity
|
20 CST (Below)
|
|
Working Medium
|
Air,Water,Oil,Gas
|
|
Motion Pattern
|
Direct Drive Type
|
|
Type
|
Normal Close Type
|
|
Operation Fluid Viscosity
|
20 CST(Below)
|
|
Operating Temperature Range |
-5 ~ +80℃
|
|
Voltage Range
|
±10%
|
|
Working Medium
|
Air,Water,Oil,Gas
|
|
Motion Pattern
|
Direct Drive Type
|
|
Type
|
Normal Close Type
|
|
Operation Fluid Viscosity
|
20 CST(Below)
|
|
Max. Pressure Resistance |
1.0 MPa
|
|
Operating Temperature Range |
-5 ~ +80℃
|
|
Working Medium
|
Air,Water,Oil,Gas
|
|||||
|
Motion Pattern
|
Direct Drive Type
|
|||||
|
Type
|
Normal Close Type
|
|||||
|
Operation Fluid Viscosity
|
20 CST(Below)
|
|||||
|
Max. Pressure Resistance |
1.0MPa
|
|||||
|
Operating Temperature Range |
-5 ~ +80℃
|
|||||
|
Working Medium
|
Air,Water,Oil,Gas
|
|
Motion Pattern
|
Direct Drive Type
|
|
Type
|
Normal Open Type
|
|
Operation Fluid Viscosity
|
20 CST(Below)
|
|
Max Pressure Resistance
|
1.05MPa
|
|
Operating Temperature Range
|
‐5～+80℃
|
|
Working Medium
|
Air, Water, Oil
|
|
Motion Pattern
|
Direct Drive Type
|
|
Type
|
Normal Close Type
|
|
Operation Fluid Viscosity
|
50 CST
|
|
Working-pressure |
0~0.7MPa
|
|
Max. Pressure Resistance
|
1.05MPa
|
|
Working Medium
|
Air.Water.Oil
|
|
Motion Pattern
|
Guide Type
|
|
Type
|
Normal Close Type
|
|
Operation Fluid Viscosity
|
50 CST(Below)
|
|
Working-Pressure
|
0.05~1.0MPa
|
|
Max. Pressure Resistance
|
1.5MPa
|
|
Working Medium
|
Air.Water.Oil
|
|
Motion Pattern
|
Guide Type
|
|
Type
|
Normal Close Type
|
|
Operation Fluid Viscosity
|
50 CST(Below)
|
|
Working-Pressure
|
0.05~1.0MPa
|
|
Operating Temperature Range
|
-10~+180℃
|
|
Working Medium
|
Air,Water,Steam
|
|
Motion Pattern
|
Direct Drive Type
|
|
Type
|
Normal Close Type
|
|
Working-pressure |
0~1.0MPa
|
|
Port Size
|
G3/4”~G1-1/2”
|
|
Max Operating Differential Pressure
|
1.0MPa
|
|
Min Operating Differential Pressure
|
0.031MPa
|
|
Exhaust Orifice
|
Rc(PT)1/4
|
|
Working Medium
|
22: Air,Water,Oil
|
23: Air
|
|
|
Port Size
|
G1/8”~G1/4”
|
||
|
Voltage Range
|
±10%
|
||
|
Material of oil seal
|
NBR or VITON
|
||
|
Working Medium
|
Air, Water, Oil
|
|
Motion Pattern
|
Guide Type
|
|
Type
|
Normal Close Type
|
|
Operating Temperature Range
|
-5~+150
℃
|
|
Voltage Range
|
±10%
|
|
Protect Class
|
IP65
|
|
Working Pressure
|
0.03~1.0Mpa
|
|
Environment Temperature
|
-10~+55℃
|
|
Medium Temperature
|
-10~+90℃
|
|
PowerVoltage
|
AC:50Hz 24V,36V,110V,220V, DC:24V,12V
|
|
Working Medium
|
Air, Water, Oil, Gas
|
|
Motion Pattern
|
Direct Drive Type
|
|
Working Pressure Range
|
0~0.7MPa
|
|
Max. Pressure Resistance
|
1.05MPa
|
|
Control Pressure Range
|
0.3~0.6MPa
|
|
Operating Temperature Range
|
-5~+100℃
|
Normal Close, avaiable body: brass, SS316
Multiple seals are available for different medium.
Wide size range from 1/8" to 2" with both thread and flange connection
Diaphragm pilot solenoid valve, with lower working pressure.
