Pneumatic Tube Fittings
SERIES: Pneumatic Tube Fittings
Pneumatic Tube Fittings
FEATURES
One-Touch push-to-connect configuration allows an instant tubing connection.Smooth-Edge release sleeve design facilitates a quick tubing disconnection.
Ordering Code
Specification
Fliud Type
Air,Vacuum
Operating Pressure
0~10.2Kgf/cm2(0~1.0Mpa)
Negative Pressure
-750mm Hg(10Torr)
Operating Temperature Range
0~60℃
Tube Material
Nylon and Polyurethane


(1)Model Type
(2)Tube Outer Diameter(ΦD)

Metric Tube
Inch Tube
Code
04
06
08
10
12
14
16
1/4"
5/16"
3/8"
Φ D
4mm
6mm
8mm
10mm
12mm
14mm
16mm
1/4"
5/16"
3/8"


(4)Body Color Code
NO Code:Black Color C:Gery Color

Taper Pipe Thread

R(PT)Thread
Code
01
02
03
04
Size
R1/8"
R1/4"
R3/8"
R1/2"


G(PF)Thread
Code
G01
G02
G03
G04
Size
G1/8"
G1/4"
G3/8"
G1/2"


NPT Thread
Code
N1
N2
N3
N4
Size
NTP1/8"
NTP1/4"
NPT3/8"
NPT1/2"
Other info
Model
