Stop Fittings
SERIES: Stop Fittings
Stop Fittings
FEATURES
|
Flow of air is completely stopped upon disconnectiong the tube and reinstated upon reconnecting the tube. Dual-passage mechanism allows the pressure source to be originated from either side of the pneumatic connection. |
Specification
|
Fliud Type
|
Air,Vacuum
|
|
Operating Pressure
|
0~10.2Kgf/cm2(0~1.0Mpa)
|
|
Negative Pressure
|
-750mm Hg(10Torr)
|
|
Operating Temperature Range
|
0~60℃
|
|
Tube Material
|
Nylon and Polyurethane
|
