Series: XHC Series Style Air Gripper
|
|
Air |
||
|
|
0.7MPa |
||
|
|
-10-60℃ |
||
|
|
180(C.P.M) |
60(C.P.M)
|
|
|
|
±0.01 |
±0.02
|
|
|
|
Not required |
||
|
Bore(mm) |
10 |
16 |
20 |
25 |
|||
|
Working Medium |
Air(to be filtered by 40μm filter element) |
||||||
|
Operating pressure MPa |
Double Acting
|
0.25~0.6Mpa
|
|||||
|
Single Acting
|
0.1~0.6Mpa
|
||||||
|
Ambient fluid temperature |
-10-60℃ |
||||||
|
The highest frequency of use(c.p.m) |
180(C.P.M) |
||||||
|
Repeatability Precision(mm) |
±0.01 |
||||||
|
Lubrication |
Not required |
||||||
|
Port Size |
M3×0.8 |
M5×0.8 |
|||||
'
